Mondraker Trick 16

ADULT TECH TO MAKE YOU FEEL LIKE A KID

The new Trick rewrites everything compared to the old Leader, as this year brings a fresh new frame design with a design language clearly influenced by our high-end adult bikes. Minimalistic frame tubes, straighter lines, and details such as the top tube flowing into the seat stays in an almost straight line, and nothing says ‘Mondraker’ more than the ‘window’ between the top tube, the down tube and the headtube now featured on the Trick too.

All the frames are made from Alloy Stealth Evo and our Forward Geometry has been 100% tweaked to best suit kids’ needs. Internally guided cable routing is featured, as is 12x142mm rear hub spacing, a UDH mech hanger and 2.4” tyres. This tyre width is fundamental as it makes a huge difference to the grip available on tricky terrain, thus increasing confidence, and allows for lower tyre pressures in general to aid with comfort and control.

Frame
Trick 16 6061 Alloy Stealth Evo, HHG internal cable routing, internal headset, replaceable hanger, BSA bottom bracket, 3/8x135mm rear axle

Sizes
One size – 210mm

Fork
MDK 16 Kid, alloy stanchions, chromoly steering tube

Headset
FPD Dozer tapered internal 1048AS, 1-1/8″–1-1/2″, 15mm top cover + TJ3 top cap

Stem
MDK XC, 6061 forged alloy, 25.4mm barbore, 0º rise, 40mm length

Handlebar
MDK XC 1.0, 6061 alloy, 19mm rise, 540mm width, 9º backsweep, 5º upsweep, 25.4mm barbore

Grips
Onoff Kids 19, 100mm

Seatpost
MDK XC, 6061 T6 alloy, 27.2mm diameter, 200mm length, 0mm offset

Saddle
Mondraker Leader Kids Series

Front Brake
Clarks M2 Junior, 140mm IS 6-bolt, one-piece rotor

Rear Brake
Clarks M2 Junior, 140mm IS 6-bolt, one-piece rotor

Brake Lever
Clarks M2 Junior

Rims
MDK-XP1 20, 25mm internal width, 20 spokes

Spokes
CN round stainless steel

Front Hub
KT-K8QF, 9x100mm QR axle, cup & cone ball bearings

Rear Hub
MSR 1B4, 3/8x135mm, cup & cone ball bearings

Front Tire
Kenda Booster 16×2.2, single compound, 30TPI, wire bead

Rear Tire
Kenda Booster 16×2.2, single compound, 30TPI, wire bead

Crankset
Prowheel DM 28, 102mm

Chainring
28T

Bottom Bracket
CH-52

Pedals
NW-450 PP

Chain
KMC Z-9, 9s

Cassette
HG Driver 16T, 1s

Weight
7.2 kg
