Race Face Ar40 offset 29″ rim

74,90€

A New Slant
The all-around rad AR rims have been slightly adjusted with a new asymmetrical profile. Fully dialed to be stiffer, stronger, and optimally balanced, these highly versatile rims come in every width imaginable to cover XC to plus bikes and everything in between.

Out of stock, coming to stock 10.6.2026

Our popular AR rims have been updated for 2019 with our asymmetric rim profile, improving spoke tension balance and overall wheel build quality and durability. The rim extrusion has also been improved to increase impact performance for more aggressive applications. With 5 widths available, tubeless compatible rim profile, and color match capabilities, these rims are ready for any build you can throw at them.

PRODUCT FEATURES

Material: 6069 aluminum
Available Diameters: 27.5″, 29″
Tubeless Ready: Yes
Rim ERD: 558 mm (27.5″ rim) / 596 mm (29″ rim)
Rim Height: 22 mm
Rim Offset: 4.5 mm

Model: AR Offset 25, Hole Count: 32, Tubeless: Yes, Max Tension: 1200 N / 122 KgF, Use: XC / Trail, ETRTO: 584x25c / 622x25c, Weight: 448 +/-5% / 470 +/-5%, Offset: 3, ERD: 562 / 600

Model: AR Offset 27, Hole Count: 32, Tubeless: Yes, Max Tension: 1200 N / 122 KgF, Use: Trail / AM, ETRTO: 584x27c / 622x27c, Weight: 490 +/-5% / 520 +/-5%, Offset: 3.8, ERD: 562 / 600

Model: AR Offset 30, Hole Count: 32, Tubeless: Yes, Max Tension: 1200 N / 122 KgF, Use: Trail / AM / Enduro, ETRTO: 584x30c / 622x30c, Weight: 514 +/-5% / 545 +/-5%, Offset: 4.5, ERD: 562 / 600

Model: AR Offset 35, Hole Count: 32, Tubeless: Yes, Max Tension: 1200 N / 122 KgF, Use: Trail / AM / Enduro, ETRTO: 584x35c / 622x35c, Weight: 552 +/-5% / 583 +/-5%, Offset: 4.5, ERD: 562 / 600

Model: AR Offset 40, Hole Count: 32, Tubeless: Yes, Max Tension: 1200 N / 122 KgF, Use: Trail / AM, ETRTO: 584x40c / 622x40c, Weight: 595 +/-5% / 626 +/-5%, Offset: 4.5, ERD: 562 / 600
