Mondraker Crafty Carbon RR

Frame
Crafty Stealth Air full Carbon front triangle, Stealth Alloy rear triangle, Updated Zero Suspension System, 150mm travel, Forward Geometry, internal removable battery, Boost 12x148mm rear axle, UDH, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 15mm axles, exclusive plastic motor covers.

Sizes
S: 380mm / M: 410mm / ML: 435mm / L: 460mm / XL: 490mm

Rear shock
Fox Float X Factory Kashima EVOL, 185x55mm. Settings: 2-position compression (Open/Firm), rebound, air preload. Trunnion top mount, 30x8mm bottom bushings

Shock settings
CS40 compression, RL70 rebound, Rezi B40, LML, 0.2 volume spacer

Fork
Fox 38 29 Float GRIPX2 Factory Kashima, 160mm, tapered steerer tube, Boost 15x110mm Kabolt axle, 44mm offset. Settings: high and low-speed compression, high and low-speed rebound, air preload

Headset
Acros custom ZS56/ZS56, 1-1/8″, 1.5″ head tube, Internal cable routing, sealing plugs without blocklock

Stem
Onoff S6 30mm 0º, 6061 forged alloy + CNC, 31.8mm barbore

Handlebar
Onoff S6 1.0 7050 alloy, rise: 25mm, width: 800mm, 8º backsweep, 5º upsweep, 31.8mm barbore. L and XL size: 38mm rise.

Grips
Onoff Desert Pro, CNC lock-on, 135mm. L and XL: Thicker size

Seatpost
Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing

S size: 140–115mm (388–235mm)

M size: 160–135mm (428–255mm)

ML size: 180–155mm (468–275mm)

L size: 210–185mm (528–305mm)

XL size: 210–185mm (528–305mm)

Saddle
Ergon SM-10

Front brake
Sram Maven Bronze, 18 and 19.5-millimeter 4-piston caliper, HS2 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads

Rear brake
Sram Maven Bronze, 18 and 19.5-millimeter 4-piston caliper, HS2 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads

Brake lever
Sram Maven Bronze, SwingLink and lever pivot bushings, tools-free reach adjust

Rims
Mavic E-Deemax 29, 30mm internal width, welded, PFP, tubeless ready, 28 spokes

Spokes
Mavic J-bend double butted, contactless lacing

Front hub
Mavic, Boost 15x110mm, IS 6 bolts

Rear hub
Mavic, Boost 12x148mm, ID360 Ratchet system, IS 6 bolts, XD freehub

Front tire
Maxxis Assegai 29×2.5WT, tubeless ready, 3C Maxx Grip compound, EXO+ protection, 60TPI, folding bead

Rear tire
Maxxis Minion DHR II 29×2.5 WT, tubeless ready, 3C MaxxTerra compound, DD protection, 2x120TPI, folding bead

Crankset
Race Face Aeffect-R ebike, 160mm

Rings
Sram Eagle 34T T-Type, direct mount, steel, CL55

Chain
Sram GX Eagle T-Type, 12s, Powerlock

Rear derrailleur
Sram GX Eagle AXS, T-Type, 12s

Shift levers
Sram Eagle AXS Pod MMX, 12s

Casette
Sram XS-1275, 10-52T, T-Type, 12s

Weight
24,4 kg

Display
Kiox 400 / Bosch Mini Remote

Motor
Bosch Performance Line CX (25Km/h) SMART SYSTEM (BDU384Y)

Battery
Bosch Powertube 800Wh
