E-SYSTEM: SHIMANO STePS EP6, Auto Shift compatible, Boost 400%, Trail 180%, Eco 60%, Peak output 500W
DISTANCE: 120km
MAX. TORQUE: 85Nm / 400%
MOTOR: SHIMANO STEPS EP600, 36V, 250W, 85Nm, Auto Shift compatible
CHARGER: DARFON 4A Smart Plus charger
BATTERY: DARFON, 36V, 504 Wh, integrated
DISPLAY: SHIMANO SC-EM800, Clamp band
SWITCH: SHIMANO EM800
FRAME: Alloy Al-6061 T6 Custom tubing, Fat Fun Geometry, Shark Spine EVO 26er Fat, SHIMANO STEPS DU hanger, 2nd Gen. battery integration, 4.8″ Tire ready, Tapered Head Tube, 197×12, Post Mount, Inner Cable Routing, Kick stand and Dropper post ready, RC470
SUSPENSION FORK: Manitou Mastodon COMP, 120mm
HEADSET: ACROS ZS44/ZS56
SUSPENSION TRAVEL FRONT: 120mm
GEAR RANGE: 1×10, 11-48, 436%
REAR DERAILLEUR: SHIMANO CUES RD-U6000 GS
CSHIFTERS RIGHT: SHIMANO CUES SL-U6000 RapidFire Plus, 10-speed
CRANKSET: ONE1 ET39-F40-SHP80-L/R, 34T
CHAINRING: 34T
CASSETTE: SHIMANO CS-LG400-10, 11-48T
CHAIN: SHIMANO CN-LG500
BRAKE FRONT: SHIMANO MT520
ROTOR FRONT: SHIMANO SM-RT66, 180mm
BRAKE REAR: SHIMANO MT520
ROTOR REAR: SHIMANO SM-RT66, 180mm
WHEELSET FRONT: WTB Fatbike Tubeless System Wheelset
WHEELSET REAR: WTB Fatbike Tubeless System Wheelset
TYRE FRONT: Maxxis Minion FBF Exo TR
TYRE REAR: Maxxis Minion FBR Exo TR
STEM: ONE1 TDS-D607 Alloy, 35MM, +7°
HANDLEBAR: ONE1 Alloy, 9° backsweep, 20mm rise, 760mm, 35mm
GRIPS: HERRMANS ERGO
SADDLE: WTB Koda Sport
SEATPOST: ONE1 Alloy, MT171, dropper post 170mm, 30.9mm
PEDALS: Steel caged w/reflector
